Products Catalog
Electrical

Thermal military/aerospace Circuit Breaker. Non compensated, high performance. 15/32'' bushing. Uses minimum space. Light weight. Trip free. 7 1/2 AMP.

MPN: 5925-01-125-5722

Manufacturer: Sensata

Aircraft Circuit Breaker-single phase, miniature ambient compensated and trip free

MPN: 5925-01-126-2378

Manufacturer: Sensata

20 AMP Thermal commercial aircraft Circuit Breaker-single phase, miniature ambient compensated and trip free. High vibration resistance.

MPN: 5925-01-126-2379

Manufacturer: Sensata

Fully sealed magnetic Circuit Breaker, low power, trip free, one pole, screw Terminals, rated 5.0 amps, high inrush, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-138-7931

Manufacturer: Airpax

Boeing spec aircraft Circuit Breaker 2 1/2 amps.

MPN: 5925-01-142-7773

Manufacturer: Sensata

Hydraulic magnetic Circuit Breaker, QPL to MIL-PRF-55629, triple pole with auxiliary Switch, rated 25 amps @ (either 50VDC, 240VAC, 50/60Hz or 400Hz).3 pole, military breaker, w/ aux. Switch, black toggle Handles, 25A, 240VAC, 400Hz, 42 delay. See attached link for exact amperage rating.

MPN: 5925-01-148-4709

Manufacturer: Airpax

Commercial aircraft Circuit Breaker. Single phase,non compensated,aux contacts,general application. Miniature size. Light weight. Trip free design. 1/2 AMP.

MPN: 5925-01-149-6961

Manufacturer: Sensata

Thermal 50 amp Circuit Breaker. Precision,sealed and ignition protected. Manual reset. Self locking mounting nut for easy installation. Provides excellent over-current protection for harsh environments.

MPN: 5925-01-150-4465

Manufacturer: Sensata

Fully sealed magnetic Circuit Breaker with auxiliary contacts, low power, trip free, two pole, rated 2.5 amps, standard delay, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-168-1801

Manufacturer: Airpax

Thermal aerospace Circuit Breaker, single phase, miniature ambient compensated. High performance, trip-free "state of the art" protection. 35 amp.

MPN: 5925-01-173-1763

Manufacturer: Sensata

Military/aerospace Circuit Breaker. Thermal 3 phase, miniature, ambient compensated. Trip free and lightweight. Vibration pads improve mounting stability. 4 amps.

MPN: 5925-01-173-7285

Manufacturer: Sensata

3-phase, 50 amp, also known as NSA931304-5005, ambient compensated aircraft grade thermal Circuit Breaker. Klixon 6752-300 series thermal magnetic Circuit Breakers are designed and manufactured to meet more stringent military standards of today's jet aircraft electrical systems. The higher interrupting capacity, vibration resistance and longer cycling life exceeds previous military standards.

MPN: 5925-01-174-5403

Manufacturer: Sensata

Thermal military/aerospace Circuit Breaker. Non compensated, high performance. 15/32'' bushing. Uses minimum space. Light weight. Trip free. 2 1/2 AMP.

MPN: 5925-01-189-4082

Manufacturer: Sensata

Aircraft mil spec Circuit Breaker. 7 /12 amps. MS25244 but ALTERNATE BASE & Terminal CONFIGURATION STYLE, A feature of the breaker is separate overload and mechanical latches. Separated in this way,the mechanical latch assures maximum endurance for the thousands of cycles of manual on-off operation, while the thermal latch combines both precise operation and durability.

MPN: 5925-01-208-0617

Manufacturer: Safran

Commercial thermal Circuit Breaker. 60 amps. Sealed & ignition protected. Manual reset. Stud Terminals. Self locking nut. For battery protection in electric vehicles & marine. Ignition protected to SAE J1171: Weatherproof to SAE J553. UL Recognized to E36869.

MPN: 5925-01-208-3476

Manufacturer: Sensata

Hydraulic magnetic Circuit Breaker, QPL to MIL-PRF-55629, three pole, unsealed, trip free, rated 15 amps @ (either 50VDC, 240VAC, 50/60Hz or 400Hz). See attached link for more specific information.

MPN: 5925-01-213-6396

Manufacturer: Airpax

3-phase, 10 amp, also known as, ambient compensated aircraft grade thermal Circuit Breaker. Klixon 6752-300 series thermal magnetic Circuit Breakers are designed and manufactured to meet more stringent military standards of today's jet aircraft electrical systems. The higher interrupting capacity, vibration resistance and longer cycling life exceeds previous military standards.

MPN: 5925-01-216-0287

Manufacturer: Sensata

Fully sealed magnetic Circuit Breaker, low power, trip free, one pole, rated 1.5 amps, high inrush, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-223-1063

Manufacturer: Airpax

Military/aerospace Circuit Breaker. Thermal 3 phase, miniature, ambient compensated. Trip free and lightweight. Vibration pads improve mounting stability. 2 amps.

MPN: 5925-01-223-2072

Manufacturer: Sensata

Fully sealed magnetic Circuit Breaker with auxiliary contacts, low power, trip free, three pole, rated 5.0 amps, high inrush, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-225-6808

Manufacturer: Airpax
