5 Series Products

Micro Switch TL Series Sealed Toggle Switch, 4PDT - 4 pole, 2 position (Momentary ON - OFF), Screw Terminal, Standard Lever, Military Part Number MS24525-26.

MPN: 5930-00-660-3955

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, 4PDT - 4 pole, 2 position (Momentary ON - OFF), Screw Terminal, Standard Lever, Military Part Number MS24525-30.

MPN: 5930-00-660-3961

Manufacturer: Honeywell

General purpose pushbutton Switch, AC rated, non-illuminated, Normally open (NO), one hole mounted, light duty, momentary contact, 1PST, 5A at 12VDC), 3A at 125VAC, black button, screw Terminals. Special order 50 pcs minimum NCNR. Allow 5 weeks for delivery

MPN: 5930-00-660-4216

Manufacturer: Eaton

Special enclosed Switch-with elastomer plunger seal and Amphenol Connector attached, 2 X SPDT contact arrangement, 15A at 125V - see attached PDF for more specs.

MPN: 5930-00-669-7467

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 3 Position (On - Off - On), Screw Terminals, Standard Lever, Military Part Number MS24523-21. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-681-4727

Manufacturer: Honeywell

Switch Guard, MIL-G-7703, Flush Mount for Full Throw Single Throw Switches, Returns lever to off position, Phenolic Red Lever.

MPN: 5930-00-681-4897

Manufacturer: Safran

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 2 Position, Half Throw (On - On), Screw Terminals, Standard Lever, Military Part Number MS24523-33. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-683-1522

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 2 Position, Half Throw (ON - Momentary ON), Screw Terminals, Standard Lever, Military Part Number MS24523-32. Ampere/Voltage Range (Resistive Load): 0.5 A at 250 Vdc; 0.75 A at 115 Vdc; 0.5 A to 15 A at 0.5 Vdc to 28 Vdc; 0.5 A to 10 A at 0.5 Vac to 277 Vac. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-683-1624

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position (Momentary OFF - ON), Screw Terminals, Standard Lever, Military Part Number MS24523-29. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-683-1627

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 2 Position (On - On), Screw Terminals, Standard Lever, Military Part Number MS24523-23. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-683-1629

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position, Half Throw (Off - On), Screw Terminals, Standard Lever, Military Part Number MS24523-24. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-683-1630

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 2 Position (Momentary ON - ON), Screw Terminals, Standard Lever, Military Part Number MS24523-26. Ampere/Voltage Range (Resistive Load): 0.5 A at 250 Vdc; 0.75 A at 115 Vdc; 0.5 A to 15 A at 0.5 Vdc to 28 Vdc; 0.5 A to 10 A at 0.5 Vac to 277 Vac. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-683-1632

Manufacturer: Honeywell

Rugged sealed mil spec toggle Switch, MIL-DTL-3950 & MS24523-27 Approved, 15A @ 28 VDC & 115 VAC 60 or 400 Hertz Resistive Load, S.P.S.T. Momentary ON-OFF-Momentary ON, Environmentally Sealed, Screw Terminals. Sealed to IP68.

MPN: 5930-00-683-1633

Manufacturer: Safran

Sealed Military Spec Pushbutton Switch. 10A, 2 circuit, Screw Terminals, Momentary, Black Button. Hardware included. Same as Otto P1-12622.

MPN: 5930-00-683-5536

Manufacturer: Otto

Sealed Military Spec Pushbutton Switch. 10A, 3 Terminal normally open, Screw Terminals, Momentary, Black Button. MS25089-4A. Hardware included. Same as Otto P1-12422.

MPN: 5930-00-683-6006

Manufacturer: Otto

Rugged Military Aerospace Toggle Switch, Environmentally Sealed Positive Action, 15A @ 28 VDC or 115 VAC 60 or 400 Hertz Resistive load, S.P.S.T. ON-NONE-ON Circuitry. 8836K4 is mil qualified to MS25306-232. Non- teasible Switch mechanism, molded in Terminal numbers, solderable screw Terminals. Environmentally sealed per MIL-S-8834.

MPN: 5930-00-686-0370

Manufacturer: Safran

Leaf auxiliary Actuator, basic switches, Corrosion resistant steel. Screw mounting.

MPN: 5930-00-686-3680

Manufacturer: Honeywell

Miniature pushbutton Switch, N.O. normally open, SPST, molded in solder lug Terminals. red button. 39-1 pushbutton Switch requires a minimum amount of space. Rated at 150 mA to 1/2 Amp.

MPN: 5930-00-686-9533

Manufacturer: Grayhill

Switch Guard,MIL-G-7703 & MS24417-1,One Hole Mount for 2 or 3 Position Switches. 8492k1 insertion of pin (not provided) through guard prevents accidental operation, Black Metal Lever, Keyway Opp. Pin Hole. Specially priced for this lot of only!

MPN: 5930-00-687-1079

Manufacturer: Safran

Micro Switch TL Series Sealed Toggle Switch, 4PDT - 4 pole, 3 position (Momentary ON - OFF - ON), Screw Terminal, Standard Lever, Military Part Number MS27406-2.

MPN: 5930-00-687-1649

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, 4PDT - 4 pole, 2 position (ON-ON), Screw Terminal, Locking Lever (D) - Locked out of center position, Military Part Number MS24525-23D.

MPN: 5930-00-687-1960

Manufacturer: Honeywell

Sealed Military Spec Pushbutton Switch. 10A, 3 Terminal , normally closed circuit, Screw Terminals, Momentary, Red Button. Mil spec to MS25089-5AR. Hardware included. Same as Otto P1-12321.

MPN: 5930-00-687-1973

Manufacturer: Otto

Environmentally Sealed Positive Action Toggle Switch, two pole, ON- OFF - ON circuitry, Screw Terminals, 25A (resistive) at 28 VDC, 115 VAC and 400Hz; or 20A (resistive) at 115 VAC and 60Hz.

MPN: 5930-00-702-6431

Manufacturer: Safran

Enclosed Switch, SPDT, Top Plunger, 4 amps, 28 VDC, corrosion resistant steel Enclosure, Sealed per MIL-PRF-8805 symbol 4

MPN: 5930-00-709-1054

Manufacturer: Honeywell

Pushbutton Switch, 15A 120 VAC, 1A 120 VDC, 1.P.D.T.-2 Circuit, Momentary, Black Button, Clear Case, Screw Terminals. MS16712-1

MPN: 5930-00-726-8805

Manufacturer: Safran

Toggle Switch Guard, MIL-G-7703 & MS25214-3,One Hole Mount for 3 Position Switches, Returns lever from either extreme position to center position, Phenolic Red Lever, Keyway Hinged End.

MPN: 5930-00-729-9852

Manufacturer: Safran

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (ON-OFF-ON), Screw Terminal, Standard Lever

MPN: 5930-00-752-2717

Manufacturer: Honeywell

Lever Lock, Environmentally Sealed Positive Action, MIL-DTL-8834 & MS24612-E222, 25A @ 28 VDC or 115 VAC 400 Hertz or 20A 115 VAC 60 Hertz Resistive Load, S.P.D.T. ON-NONE-OFF with lever lock Actuator. Screw Terminals.

MPN: 5930-00-756-0333

Manufacturer: Safran

General purpose pushbutton Switch, AC rated, Normally closed (NC), Flush Mounted, light duty, momentary contact, 1PST, 3/4A at 125V (AC/DC), 1/4A at 250V (AC/DC), black button, screw Terminals

MPN: 5930-00-761-2146

Manufacturer: Eaton

Micro Switch Basic Switch, SPDT, 5A resistive at 30 Volts DC, N.O/N.C.

MPN: 5930-00-764-3134

Manufacturer: Honeywell
