5 Series Products

Micro Switch TL Series Sealed Toggle Switch, SPDT - 1 pole, 3 position (ON-OFF-ON), Screw Terminal, Locking Lever (E) - Locked in center position, Military Part Number MS24658-21E.Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc|0.75 A at 115 Vdc|0.5 A to 15 A at 0.5 Vac to 277 Vac|0.5 A at 250 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-042-7034

Manufacturer: Honeywell

AC rated Heavy Duty toggle Switch, military purpose - MIL-S-83731 with lever seal, screw Terminals, 18 amps at 28VDC, 11 amps at 115VAC/60Hz, 11 amps at 115VAC/400Hz, 1P3T in a 2P base, ON - ON - Momentary ON circuitry

MPN: 5930-00-044-3514

Manufacturer: Eaton

AC rated Heavy Duty toggle Switch, military purpose - MIL-S-83731 with lever seal, screw Terminals, 18 amps at 28VDC, 11 amps at 115VAC/60Hz, 11 amps at 115VAC/400Hz, 1P3T in a 2P base, Momentary ON - ON - Momentary ON circuitry

MPN: 5930-00-044-3518

Manufacturer: Eaton

Toggle Switch. 8869K6 is a Miniature positive action toggle Switch with solder lug Terminal to MIL-S-8834. MS90311-281 is a double pole Switch with off none on (momentary)

MPN: 5930-00-051-0727

Manufacturer: Safran

Switch-refer to attached drawing for specs.

MPN: 5930-00-052-6589

Manufacturer: Sensata

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (ON-ON), Screw Terminal, Locking Lever (F) - Locked in extreme position (opposite keyway), Military Part Number MS24659-23F

MPN: 5930-00-057-4760

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - OFF - Momentary ON), Screw Terminal, Tab Lever - rectangular white plastic

MPN: 5930-00-063-7213

Manufacturer: Honeywell

Special enclosed aircraft Switch-see attached PDF.

MPN: 5930-00-068-7932

Manufacturer: Honeywell

Environmentally sealed positive action toggle, single pole, ON-OFF-ON circuit try, screw Terminals, 25A (resistive) @ 28 VDC or 115 VAC 60 or 400 Hertz.

MPN: 5930-00-069-2390

Manufacturer: Safran

Micro Switch BZ Series Premium Large Basic Switch, Single Pole Double Throw Circuitry, 15 A at 250 Vac, Overtravel Plunger Actuator, 2,5 N - 3,61 N [9 oz - 13 oz] Operating Force, Silver Contacts, Screw Termination, CE, CSA, DEMKO,.

MPN: 5930-00-076-3244

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - OFF - ON), Screw Terminal, Locking Lever (P) - locked out of and into extreme position (keyway), Military Part Number MS27408-4P

MPN: 5930-00-082-1654

Manufacturer: Honeywell

Environmentally sealed limit Switch with Leadwire termination, Top Roller Plunger actuation, Double Pole Double Throw, Double Break (2 CKT DB) Circuitry, 15 A (Resistive) ampere rating at 28 Vdc, 2PDT-DB

MPN: 5930-00-082-7022

Manufacturer: Honeywell

Miniature Mil Spec Toggle Switch with Positive Switching Action, 5A @ 28 VDC, 3A @ 115 VAC 400 Hertz, 2A @ 115 VAC 60 Hertz Resistive Load, S.P.D.T. NONE-OFF-MOMENTARY ON circuitry. The 8868K6 has a full bushing seal, solder lug Terminals and is fully mil qualified to MS90310-281.

MPN: 5930-00-088-8762

Manufacturer: Safran

Sealed Military Spec Pushbutton Switch. 10A, 2 circuit, Screw Terminals, Momentary, Black Button. Hardware included. Same as Otto P1-82622.

MPN: 5930-00-104-6148

Manufacturer: Otto

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - ON - Momentary ON), Screw Terminal, Standard Lever, Military Part Number MS27407-3.

MPN: 5930-00-105-5331

Manufacturer: Honeywell

Switch, Sealed Military Spec Pushbutton Switch. 10A, normally open SPST, Screw Terminals, Momentary, Black Button. MS25089-1G. Hardware included. Same as Otto P1-72122.

MPN: 5930-00-109-9818

Manufacturer: Nexus

Sealed Military Spec Pushbutton Switch. 10A, normally open SPST, Screw Terminals, Momentary, Red Button. MS25089-1GR. Hardware included. Same as Otto P1-72121.

MPN: 5930-00-110-1113

Manufacturer: Otto

Weather and dust proof momentary push button Switch. 2 Position- Off- On Normally Off (Push to On). 40 Amps@ 24VDC. 60 Amps@ 12VDC.

MPN: 5930-00-111-8619

Manufacturer: Pollak

Sealed Military Spec Pushbutton Switch. 10A, normally open, SPST, Screw Terminals, 4 lbs. momentary action, black button. Mil Grade MIL-PRF-8805/3 Momentary Action, Snap Action, Double Break. Hardware included. Same as Otto P1-82122.

MPN: 5930-00-112-4417

Manufacturer: Nexus

TL Series Toggle Switch, DPDT - 2 pole, 2 position (OFF-ON), IWTS (14-16 Gage) Terminal, Standard Lever, Military Part Number MS27723-22 Ampere/Voltage Range (Resistive Load): 0.75 A at 115 Vdc; 0.5 A at 250 Vdc; 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac. UL/CSA: L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-114-5488

Manufacturer: Honeywell

Wide Button Moisture proof /splash proof Pushbutton Switch-Single pole single throw normally open. Black button and body. Solder Terminals. Rated at 10 amps resistive at 28VDC or 125VAC.

MPN: 5930-00-116-2762

Manufacturer: Safran

Micro Switch BZ Series Premium Large Basic Switch, Single Pole Double Throw Circuitry, 15 A at 125 Vac, Straight Lever Actuator, 0,28 N [1 oz] Maximum Operating Force, Silver Contacts, Screw Termination, CE, CSA, DEMKO, UL.

MPN: 5930-00-147-0696

Manufacturer: Honeywell

Micro Switch SX Series Subminiature Basic Switch, Single Pole Double Throw (SPDT), 250 Vac, 5 A, Pin Plunger Actuator, Solder Termination.

MPN: 5930-00-175-5903

Manufacturer: Honeywell

Mini push button space saving Switch, Black button. Circuitry: SPST NO (normally open).Rating: 500mA at 115 VAC. Operations at Rating: 1000000. Termination: Solder Lug. Allow 10 day delivery if out of stock.

MPN: 5930-00-190-0295

Manufacturer: Grayhill

Heavy duty span action pushbutton Switch. D201W3 operation force 2.5 lbs. SPNO 4 Terminal. Electrical life 25,000 operations.

MPN: 5930-00-221-8951

Manufacturer: Safran

Uniform Panel Appearance Pushbutton Switches. Moisture proof. 2PDT 4 circuit may be jumper to 2PDT. See attached PDF for colors-Note-we can build these from stock even if store shows no stock-allow 1 week for delivery but they are NCNR. Assembly items that are in stock need at least 24 hours to process prior to shipping.

MPN: 5930-00-224-5815

Manufacturer: Safran

Sealed Military Spec Pushbutton Switch. 10A, 2 circuit, Screw Terminals, Momentary, Red Button. MS25089-3HR. Hardware included. Same as Otto P1-82621.

MPN: 5930-00-227-5098

Manufacturer: Otto

Military spec locking toggle Switch. 2 pole bonded seal on none off. 8856K14 has Positive make and break action and Solder lug termination.

MPN: 5930-00-233-7307

Manufacturer: Safran

Micro Switch TW Series Toggle Switch, SPDT - 1 pole, 3 position (Momentary ON - OFF - ON), Solder Terminal, Standard Lever, Military Part Number MS27718-27-1. Ampere/Voltage Range (Resistive Load): 0.1 A to 5.0 A at 0.5 Vdc to 28 Vdc; 0.1 A to 5.0 A at 0.5 Vac to 115 Vac. UL/CSA L117: 5 A at 125 Vac. Qualified to MIL-DTL-83731.

MPN: 5930-00-238-0801

Manufacturer: Honeywell

Switch base for Dialight 513 series.

MPN: 5930-00-238-5630

Manufacturer: Dialight
