Micro Switch TL Series Toggle Switch, DPST - 2 pole, 2 position (OFF-ON), Screw Terminal, Locking Lever (F) - locked in etreme position (opposite keyway), Military Part Number MS24659-22F.

MPN: 5930-00-434-3222

Manufacturer: Honeywell

Sealed Military Spec Pushbutton Switch. 10A, normally open SPST, Screw Terminals, Momentary, Red Button. Military Spec part #MS25089-1AR. Hardware included.

MPN: 5930-00-451-5731

Manufacturer: Otto

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - ON - ON), Screw Terminal, Locking Lever (K) - Locked in center and extreme position (opposite keyway), Military Part Number MS27408-5K.

MPN: 5930-00-460-1048

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPST - 2 pole, 3 position (NONE - OFF -ON), Screw Terminal, Standard Lever, Military Part Number MS24524-24.

MPN: 5930-00-581-8123

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (NONE - ON - Momentary ON), Screw Terminal, Standard Lever, Military Part Number MS24524-32.

MPN: 5930-00-655-4242

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPST - 2 pole, 2 position (ON-OFF), Screw Terminal, Standard Lever, Military Part Number MS24524-30.

MPN: 5930-00-660-3950

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 3 Position (On - Off - On), Screw Terminals, Standard Lever, Military Part Number MS24523-21. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-681-4727

Manufacturer: Unspecified

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position (Momentary OFF - ON), Screw Terminals, Standard Lever, Military Part Number MS24523-29. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-683-1627

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 2 Position (On - On), Screw Terminals, Standard Lever, Military Part Number MS24523-23. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-683-1629

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position, Half Throw (Off - On), Screw Terminals, Standard Lever, Military Part Number MS24523-24. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-683-1630

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 2 Position (Momentary ON - ON), Screw Terminals, Standard Lever, Military Part Number MS24523-26. Ampere/Voltage Range (Resistive Load): 0.5 A at 250 Vdc; 0.75 A at 115 Vdc; 0.5 A to 15 A at 0.5 Vdc to 28 Vdc; 0.5 A to 10 A at 0.5 Vac to 277 Vac. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-683-1632

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (ON-OFF-ON), Screw Terminal, Standard Lever

MPN: 5930-00-752-2717

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, SPST - 1 pole, 2 position (OFF-ON), Screw Terminal, Locking Lever (G) - Locked in extreme position (Keyway), Military Part Number MS24658-22G. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-781-7101

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, SPDT - 1 pole, 2 position (ON-ON), Screw Terminal, Locking Lever (D) - Locked out of center position Military Part Number MS24658-23D. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-811-4663

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, SPDT - 1 pole, 2 position (ON-ON), Screw Terminal, Locking Lever (F) - Locked in extreme position (opposite keyway), Military Part Number MS24658-23F. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-823-2059

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, SPST - 1 pole, 2 position (OFF-ON), Screw Terminal, Locking Lever (D) - Locked out of center position, Military Part Number MS24658-22D. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-843-8990

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position (Momentary ON - OFF), Screw Terminals, Standard Lever, Military Part Number MS24523-30. Ampere/Voltage Range (Resistive Load): 0.5 A at 250 Vdc; 0.75 A at 115 Vdc; 0.5 A to 15 A at 0.5 Vdc to 28 Vdc; 0.5 A to 10 A at 0.5 Vac to 277 Vac. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-847-7396

Manufacturer: Honeywell

Sealed Military Spec Pushbutton Switch. 10A, normally open SPST, Screw Terminals, Momentary, Black Button. Same a part # P1-32122. Hardware included.

MPN: 5930-00-847-9863

Manufacturer: Otto

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 2 position (ON-ON), Screw Terminal, Locking Lever (G) - Locked in extreme position (keyway), Military Part Number MS24659-23G.

MPN: 5930-00-856-1654

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - ON - ON), Screw Terminal, Locking Lever (M) - Locked out of and into extreme position (opposite keyway), Military Part Number MS27408-5M.

MPN: 5930-00-865-6784

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPST - 2 pole, 2 position (OFF-ON), Screw Terminal, Locking Lever (D) - Locked out of center position, Military Part Number MS24659-22D.

MPN: 5930-00-878-6734

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, SPDT - 1 pole, 2 position (ON-ON), Screw Terminal, Locking Lever (G) - Locked in extreme position (keyway), Military Part Number MS24658-23G. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-961-7984

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Double Throw (SPDT) 3 Position (On - Off - On), Screw Terminals, Locking Lever (A - Locked In Three Positions), Military Part Number MS24658-21A. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-990-1475

Manufacturer: Honeywell

Special 4 way toggle Switch with an operating force of 24-30 ounces. This OTTO mini trim Switch has SPST ( 4 Switches), quiet operation, sealed, momentary action. Please refer to pdf.

MPN: 5930-01-115-9238

Manufacturer: Otto

Controls mil grade pushbutton snap action Switch for low level Switching. Sealed with momentary action, normally open. 4 LBS momentary Switch action. Screw Terminals. Black body & button. Hardware is included. Mil qualified to MS25089-1CL. Same as Otto P1-34122.

MPN: 5930-01-163-3415

Micro Switch TL Series Toggle Switch, Single Pole Double Throw (SPDT) 3 Position (On - Off - On), Screw Terminals, Bar Actuator With 3 Fluorescent Buttons Attached to Lever By A Locking Type Internal Thread, Lever Cap Furnished Unassembled.

MPN: 5930-01-195-3037

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position (Momentary ON - OFF), Screw Terminals, Locking Lever (F - Locked In Extreme Position, Opposite Keyway), Military Part Number MS24658-30F.Ampere/Voltage Range (Resistive Load): 0.75 A at 115 Vdc|0.5 A at 250 Vdc|0.5 A to 15 A at 0.5 Vdc to 28 Vdc|0.5 A to 10 A at 0.5 Vac to 7 Vac. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-01-198-4726

Manufacturer: Honeywell

5930-01-216-8552 Push Switch

MPN: 5930-01-216-8552

Manufacturer: Otto

4 way toggle trim Switch. The T4 Mini Trim is a single pole, 4 throw, center off, momentary contact (self return to center off). Numerous button styles are available on both the Commercial and Military grade Switch versions. Mini Trims are typically press fit into control Grip or Panel mounted using versions with an 11/16 threaded case. Mini Trims are also available with multiple sealing levels to fit all applications. Please see attached PDF for the T4-0043, M9419/2-002 version.

MPN: 5930-01-560-3157

Manufacturer: Otto

5SE1 series switch

MPN: 5SE1

Manufacturer: Honeywell
