Micro Switch TL Series Toggle Switch, SPST - 1 pole, 2 position (OFF-ON), IWTS (14-16 Gage) Terminal, Standard Lever, bushing 15/32 inch, Military Part Number MS27722-22. Amp/voltage range: 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA: L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-01-009-0954

Manufacturer: Honeywell

Switch Guard, MIL-G-7703, One Hole Mount for 2 or 3 Position Switches, Closing guard does not effect toggle position, Phenolic Red Lever, Keyway Opp. Hinged end.*Note photo is for reference only- see new PDF as this toggle Switch Guard now has lever stop pins.

MPN: 5930-01-014-0493

Manufacturer: Safran

Rotary Switch. 3 pole 5 positions 1 deck. 1-17/32" diameter. Non-shorting Rotary Switch. Open Frame. .531 inch diameter Switch. Double-wiping, self-cleaning, silver-plated brass contacts. Phenolic insulation. Unique protective coating guards against tarnish and corrosion, extends shelf life.

MPN: 5930-01-018-2338

Manufacturer: ElectroSwitch

Miniature toggle, DPST On-Off-On, .410 Bat, .350 Threaded Bushing, Solder lug, Coin Silver Contacts. Lead time 3 weeks if item is not in stock.

MPN: 5930-01-021-5294

Manufacturer: ElectroSwitch

Sealed Military Spec Pushbutton Switch. 10A, normally open SPST, Screw Terminals, Momentary, Red Button. MS25089-1FR. Comes with mounting support nut. Same as Otto P1-62121

MPN: 5930-01-022-2076

Manufacturer: Otto

HM Series Hermetically Sealed Basic Switch, Single Pole Double Throw Circuitry, 3 A at 28 Vdc, Integral Lever Actuator, Solder Termination, Military Part Number MS27216-5.

MPN: 5930-01-030-5162

Manufacturer: Honeywell

76 series DIP Switch, 4 position SPST rocker. Sealed base standard. Spring and ball contact. See specifications for more information.

MPN: 5930-01-030-7015

Manufacturer: Grayhill

ET Series Toggle Switch, 1 pole, Electrically held- 2 position, Solder T type Terminal, Standard Lever, Military Part Number M5594/1-2.

MPN: 5930-01-034-7510

Manufacturer: Honeywell

Toggle Switch. 8869K11 is a Miniature positive action toggle Switch with solder lug Terminal to MIL-S-8834. MS21353-341 is a double pole Switch.

MPN: 5930-01-039-3771

Manufacturer: Safran

Environmentally Sealed Toggle Switch, 1 pole, electrically held- 2 positions, Screw Terminal, Standard Lever, Military Part Number 25ET61-S is mil qualified to M5594/1-3.

MPN: 5930-01-040-6270

Manufacturer: Honeywell

Sealed mini mil spec toggle Switch, miniature positive action non-teasible mechanism. Dry circuit (logic level loads) to power Switching levels. Wiping action contacts, positive make and break action. PC Terminals.

MPN: 5930-01-043-3006

Manufacturer: Safran

Micro Switch TL Series Sealed Toggle Switch, 4PDT - 4 pole, 3 position, Screw Terminal, Locking Lever (E) - locked in center position, Military Part Number MS27406-2E.

MPN: 5930-01-043-4402

Manufacturer: Honeywell

Environmentally sealed limit Switch. Special order allow 90-100 days fpr delivery if no stock is showing. NCNR.

MPN: 5930-01-045-8968

Manufacturer: Honeywell

Micro Switch TW Series Toggle Switch, DPDT - 2 pole, 3 position (ON-ON-ON), Solder Terminal, Standard Lever (A) - Locked in three positions, Military Part Number MS27753-34. Ampere/Voltage Range (Resistive Load): 0.1 A to 5.0 A at 0.5 Vdc to 28 Vdc; 0.1 A to 5.0 A at 0.5 Vac to 115 Vac. UL/CSA L117: 5 A at 125 Vac.

MPN: 5930-01-049-4180

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, SPDT - 1 pole, 2 position (ON-ON), IWTS (16-20 Gage) Terminal, Locking Lever F- locked in extreme position (opposite keyway), Military Part Number MS27787-23F. Ampere/Voltage range (resistive load): 0.75 A at 115 Vdc; 0.5 A at 250 Vdc; 0.5 A to 7.5 A at 0.5 Vdc to 28 Vdc; 0.5 A to 6 A at 0.5 Vac to 230 Vac. UL/CSA: L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L"

MPN: 5930-01-053-5861

Manufacturer: Honeywell

Miniature Positive Action Toggle Switch, 5A @ 28 VDC, 3A @ 115 VAC 400 Hertz,2A @ 115 VAC 60 Hertz Resistive Load,D.P.D.T. ON-NONE-ON, Bushing Seal, Straight PC Terminals.

MPN: 5930-01-055-8460

Manufacturer: Safran

Military and aircraft Switch. Military Grade Environmentally Sealed Toggle Switch, 2 pole, Electrically held 3 position, Solder T type Terminal, Standard Lever. 27ET61-T is mil qualified to M5594/3-1.

MPN: 5930-01-058-1325

Manufacturer: Honeywell

Micro Switch is qualified to MIL-DTL-3950, specification for sealed toggle Switches. It is a 1 Pole 1 position, SPST toggle Switch with Internal wiring (IWTS) 16-20 awg. The robust design of the 101TL2-6 toggle is well-suited for many military, aerospace and other demanding applications. These applications include environments where the Panels are subjected to mechanical shock, vibration, and temperature extremes as well as environments with dust, splashing or hose-directed water.101TL2-6, MS27784-30 is UL recognized, CSA certified, and CE approved for global use. If no stock please allow 30 days for delivery.

MPN: 5930-01-062-0602

Manufacturer: Honeywell

Toggle Switch. Miniature positive action toggle Switch with IWTS internally wired Terminals. MOMENTARY ON-OFF-MOMENTARY ON. Sealed bushing, non- teasable actuation. Life: 20,000 operations at rated load. 40,000 operations mechanical life Bushing thread sizes. Large Toggle and Lever Lock: 15/32" - 32 thread Accepts MIL-C-39029/1-101 Pin (pins -pins not included)

MPN: 5930-01-064-5726

Manufacturer: Safran

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - OFF - ON), IWTS (16-20 Gage) Terminal, Standard Lever, Military Part Number MS27785-1. Ampere/Voltage Range (Resistive Load): 0.75 A at 115 Vdc; 0.5 A at 250 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A to 20 A at 0.5 Vdc to 28 Vdc. UL/CSA: L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac d"L".

MPN: 5930-01-066-6328

Manufacturer: Honeywell
