MS91528-2T4B Knob

Part#: MS91528-2T4B NSN: 5355-00-151-6034

About this product MS91528-2T4B Knob. * Manufacturer certifications are shipped with your order FREE of charge

Product Images
MS91528-2T4B MS91528-2T4B MS91528-2T4B MS91528-2T4B MS91528-2T4B MS91528-2T4B

Product Details

Part Number or Model MS91528-2T4B
Description Knob
Schedule B Class
ECCN (Export Control Class) EAR99
Special Features Color is federal standard 595, no. 37038, shaft accommodation hole counterbore, 0.640 in. min diameter, 0.114 in. min depth
Shaft Accommodation Style Flatted one side
Setscrew Hole Quantity 2
Screw Drive Type Hexagon socket
Reference Marking Line
Pointer Design Nondetachable
Overall Thickness 0.760 inches minimum and 0.820 inches maximum
Overall Depth 0.520 inches minimum
Length 1.325 inches minimum and 1.375 inches maximum
Inside Width 0.222 inches minimum and 0.227 inches maximum
Gripping Surface Condition Grip aid
Inside Diameter 0.252 inches minimum and 0.254 inches maximum
Distance From Hole Center To Knob/skirt Base 0.260 inches maximum
Color Black
Attachment Method Setscrews
Style Designator Pointer
Thread Qty Per Inch (tpi) 32 screw hole
Thread Series Designator Unc screw hole
Thread Size 0.164 inches screw hole
Width 0.890 inches minimum and 0.930 inches maximum

Add to Cart

Up to quantity 24 ships same day.
buy now $42.95
each
Request a quote Call for questions and assistance
  +1 (321) 802-5889
  • NSN (National stock number)
    5355-00-151-6034
  • Manufactured By
    ELECTRONIC HARDWARE
  • ECCN (Export Control Class)
    EAR99

Alternate(s)

  • MS915282T4B
  • 5355001516034
  • 5355-00-151-6034
AeroBase Group is an ISO 9001:2015 + AS9120B audited and certified supplier.
ABG is AS9120B ISO:9001 Certified
