7270-1-20 Circuit Breaker

Part#: 7270-1-20 NSN: 5925-00-950-7444

About this product 7270-1-20 Circuit Breaker. * Manufacturer certifications are shipped with your order FREE of charge

Product Images
7270-1-20 7270-1-20 7270-1-20 7270-1-20

Product Details

Part Number or Model 7270-1-20
Description Circuit Breaker
Schedule B Class
ECCN (Export Control Class) EAR99
Actuator Function Trip-reset
Actuator Position Designation At pole one
Body Length 1.375 inches maximum
Body Style Single pole type
Body Width 0.750 inches maximum
Bushing Length 0.250 inches nominal
Case Material Metal
Center To Center Distance Between Terminals Parallel To Length 0.906 inches nominal
Circuit Protection Type Overcurrent single location
Fragility Factor Moderately rugged
Frequency In Hertz 400.0 single location
Inclosure Protection Type For Which Designed Shock resistant and vibration resistant
Internal Trip Release Configuration Series trip single location
Main Contact Tripping Mechanism Type Trip free
Manual Actuator Type And Quantity 1 toggle
Maximum Continuous Load Current Rating Per Pole 20.0 amperes ac single location and 20.0 amperes dc single location
Maximum Interrupting Capacity Current Type And Rating Per Pole I 5000.0 ac single location and 5000.0 dc single location
Mounting Facility Type And Quantity 1 threaded bushing w/panel seal
Mounting Surface To Terminal End Distance 1.343 inches maximum
Thread Size 0.469 inches
Operating Voltage Type And Rating Per Pole In Volts 115.0 ac single location and 28.0 dc single location
Pole Quantity 1
Reset Method Manual
Specification Data 96906-ms24509 government standard
Storage Type General purpose warehouse
Terminal Type And Quantity 2 tab w/screw
Thread Qty Per Inch (tpi) 32
Thread Series Designator Uns
Trip Delay Time In Seconds Per Rated Continuous Current 10.000 minimum at 200 pct single location and 70.000 maximum at 200 pct single location
Trip Release Ambient Tempurature Rating 25.0 degree celsius nominal single location
Trip Release Characteristic Time delay single location
Trip Release Method Thermal single location
Ultimate Trip Rating Of Continuous Current Rating Per Pole In Pe 145.0 all locations
Unpackaged Unit Weight 0.087 pounds
