Products Catalog
Electrical

Environmentally sealed limit Switch with Leadwire termination, Plunger actuation, DPDT Circuitry, 7 A (Resistive) ampere rating at 28 Vdc.

MPN: 5930-01-229-1154

Manufacturer: Honeywell

Micro Switch SX Series Subminiature Basic Switch, Single Pole Double Throw (SPDT), 250 Vac, 7 A, Pin Plunger Actuator, Quick Connect Termination. Micro Switch SX Series subminiature basic Switches are used for simple or precision on/off application needs. They are small, precision snap-action Switches that are ideal where savings in space and weight are important.

MPN: 5930-01-230-9311

Manufacturer: Honeywell

Very Rugged Flush Mounted Environmentally Sealed Positive Action Toggle Switch. High electrical/mechanical reliability. Non-teasible mechanism. Wiping action contacts. Positive make and break Action. Molded-in Terminal numbers. Three hole design for flush mounting. Single pole - Momentary On-OFF-Momentary On circuitry. Specially priced for this inventory lot only.

MPN: 5930-01-231-4543

Manufacturer: Safran

Micro Switch TW Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - ON - Momentary ON), Solder Terminal, Locking Lever (N) - Locked out of extreme position (opposite keyway), Military Part Number MS27719-27-1. Ampere/Voltage Range (Resistive Load): 0.1 A to 5.0 A at 0.5 Vdc to 28 Vdc; 0.1 A to 5.0 A at 0.5 Vac to 115 Vac. UL/CSA L117: 5 A at 125 Vac.

MPN: 5930-01-245-0400

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 2 position (ON-ON), IWTS (16-20 Gage) Terminal, Special Design Lever - Lever with 0.064 diameter hole Ampere/Voltage Range (Resistive Load): 0.75 A at 115 Vdc; 0.5 A to 7.5 A at 0.5 Vdc to 28 Vdc; 0.5 A to 6 A at 0.5 Vac to 230 Vac; 0.5 A at 250 Vdc.

MPN: 5930-01-251-1375

Manufacturer: Honeywell

ET Series Toggle Switch, 2 pole, environmentally sealed, electrically held- 3 position, Solder T type Terminal, Locking Lever, Military Part Number . 27ET61-T-E is mil qualified to M5594/6-1E

MPN: 5930-01-251-6742

Manufacturer: Honeywell

5000 series Pressure Switch with standard Terminals, Factory set at 60 PSI, Normally Open (N.O), single circuit - 2 Terminals.

MPN: 5930-01-252-3915

Manufacturer: Honeywell

Limit Switch, SPST, 7 amps (resistive) @ 28VDC/115VAC, Qualified per MIL-PRF-8805/4, stainless steel housing and plunger.

MPN: 5930-01-258-9663

Manufacturer: Otto

Pushbutton Switch - special case, .38 inch red button, 10A resistive at 28VDC or 115VAC, watertight per MIL-PRF-8805, Design 3, Temperature range -55 degrees C to +65 degrees C.

MPN: 5930-01-258-9669

Manufacturer: Otto

Miniature Positive Action Toggle Switch - Lever Lock/IWTS Terminals.

MPN: 5930-01-262-2925

Manufacturer: Safran

Auxiliary Switch Actuator, Corrosion resistant steel leaf lever

MPN: 5930-01-265-3658

Manufacturer: Honeywell

Switch. Environmentally Sealed Toggle Switch,2 pole,Electrically held 3 position,Solder T2 type Terminal,Locking Lever.

MPN: 5930-01-266-5426

Manufacturer: Honeywell

Toggle Switch. Military grade environment proof rugged sealed toggle Switch. 2 pole, 3 position, Screw Terminals, Standard toggle lever, 8501K2 offers DPDT (double pole double throw) circuitry and is an excellent toggle Switch for rugged environments. Features MOMENTARY ON-OFF-MOMENTARY ON circuitry.

MPN: 5930-01-269-9509

Manufacturer: Safran

Special aircraft environmentally sealed limit Switch, SPDT (2), 1A (resistive) at 28 VDC

MPN: 5930-01-271-5996

Manufacturer: Honeywell

ET Series Toggle Switch, 2 pole, Electrically held- 2 position, Connector Terminal, Locking Lever MICRO Switch ET toggle.

MPN: 5930-01-275-8237

Manufacturer: Honeywell

Rugged Snap Action Pushbutton Switch. Normally Open. Dust tight. Internal silicon rubber boot seals out contaminants. Black.160 button. 5 amps@28vdc.Solder Terminals.

MPN: 5930-01-276-2975

Manufacturer: Otto

Microphone Pushbutton Foot Operated Switch, 25A @ 28 VDC, 15A @ 115 VAC 60 or 400 Hertz, Resistive Load, 1.P.S.T. OFF-Momentary ON, Flush Mounting Screw Terminals. Longer button-see spec sheet/pdf here. Terminal Hardware included.

MPN: 5930-01-277-3263

Manufacturer: Safran

Toggle, MIL-DTL-3950 & MS24523-31 Approved, 15A @ 28 VDC & 115 VAC 60 or 400 Hertz Resistive Load, S.P.D.T. ON-OFF-Momentary ON,Environmentally Sealed, Screw Terminals. Sealed to IP68.

MPN: 5930-01-279-2994

Manufacturer: Safran

Micro Switch Subminiature basic Switch with roller, SPDT circuitry, rated for 5A @ 250 VAC, with 0.535 inch simulated roller lever and quick termination. Please see attached spec sheet for exact details.

MPN: 5930-01-282-7756

Manufacturer: Honeywell

Electrical windshield wiper Switch, electric Wiper Switch or use with Johnson Electric (formerly United Technologies) motors, black plastic Knob with metal insert and set screw, white imprint, plated steel case 1 3/8" (34.9mm) diameter, 3/8" (9.5mm) long, mounting stem 7/16" -28 thread, .38" (9.6mm) long, 5 blade Terminals, Internal 6A Circuit Breaker at 12V DC.

MPN: 5930-01-283-1097

Manufacturer: LittelFuse
