Pushbutton Switch. Double pole double throw double break. Splash and Dusttight Sealed, 2 Pole, 4 Circuit. Operating Force: 4.0 lbs. +/- 1.0 lb. Circuit: DPDT 4 circuit. Rating: 5 amps Resistive 3 amps, Inductive Contacts: Gold plate per MIL-PRF-8805/101-010, Button: Black nylon.

MPN: 5930-01-123-9994

Manufacturer: Otto

30 amp overload Sensor. Klixon 7235 and 7236 overload sensing controls are designed for the remote sensing of overloads in aircraft electrical systems or other appliCable remote systems. They are for the protection of 28 VDC circuits or for 120 VAC single phase or three phase circuits operating at 60 to 1000 Hz. For three phase AC circuit protection, a 28 VDC control circuit is required. One three phase Relay or three single phase Relays with their coils wired in series may be used in the control circuit. With either arrangement, all three phases will trip open simultaneously when an overload exists in any one phase. See attached spec sheet.

MPN: 5930-01-124-6879

Manufacturer: Sensata

ET series toggle Switch.29ET3 is 4 pole, electrically held 3 position Switch. Leadwire termination with standard lever.

MPN: 5930-01-126-2875

Manufacturer: Honeywell

Military spec locking toggle Switch. 2 pole bonded seal (ON - NONE - ON). 8856K8X has Positive make and break action and Solder lug termination.

MPN: 5930-01-126-8262

Manufacturer: Safran

Micro Switch TS Series Toggle Switch, SPST - 1 pole, 2 position (OFF-ON), Screw Terminal, Standard Lever.

MPN: 5930-01-133-3657

Manufacturer: Honeywell

Environmentally sealed limit Switch.;Plunger actuated, DPDT, NO/NC, 4 Amps / 28 Volts DC.

MPN: 5930-01-135-1677

Manufacturer: Honeywell

Micro Switch Straight lever Auxiliary Actuator for SX series Switches

MPN: 5930-01-140-2645

Manufacturer: Honeywell

Temperature range between -55 C to + 85 C. 28 VDC or 115 VAC, 10 Amp. Dust tight. Per MIL-S-8805, design 2. Nylon grey button. Black and anodized aluminum alloy case. 2 circuits. Please see drawing for more information.

MPN: 5930-01-143-9156

Manufacturer: Otto

Mil spec sub-miniature pushbutton Switch, 7A & 28 VDC & 125 VAC,S.P.S.T.-N.O. Momentary, Dust Sealed, Black Button & Case, Solder-Lug Terminals. BW9001BB is mil spec to M8805/96-014 and same as Eaton BW9001B except it has a black case. Special price for Inventory on hand only!

MPN: 5930-01-149-8527

Manufacturer: Safran

Switch roller lever Assembly, Actuator Switch.

MPN: 5930-01-156-1382

Manufacturer: Honeywell

Controls mil grade pushbutton snap action Switch for low level Switching. Sealed with momentary action, normally open. 4 LBS momentary Switch action. Screw Terminals. Black body & button. Hardware is included. Mil qualified to MS25089-1CL. Same as Otto P1-34122.

MPN: 5930-01-163-3415

Special mini pushbutton Switch white button.

MPN: 5930-01-164-8263

Manufacturer: Otto

HM Series Hermetically Sealed Basic Switch, SPDT Single Pole Double Throw Circuitry, 0.5 A at 28 Vdc, Integral Lever Actuator, Solder Termination, Military Part Number MS27216-6.

MPN: 5930-01-169-4562

Manufacturer: Honeywell

Environmentally Sealed Limit Switch with Lead wire Termination, Roller Plunger actuation, SPDT (2) Circuitry, 7 A (Resistive) ampere rating at 28 VDC.

MPN: 5930-01-169-7613

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, 4PDT - 4 pole, 3 position (Momentary ON - OFF - Momentary ON), Screw Terminal, Locking Lever (E) - Locked in center position.

MPN: 5930-01-169-7860

Manufacturer: Honeywell

Water resistant Panel seal boot, fits 7274--2, 7277-2, 2TC2 , 2TC14 and other aircraft and mil spec Circuit Breakers with a 7/16" brushing. Circuit Breaker not included. Durable silicon overmolded seal.

MPN: 5930-01-177-2847

Manufacturer: Sensata

3 Position Ignition Starter Switch with Momentary Start and Universal Type Die-Cast Housing. Please allow 8 weeks delivery if out of stock. NCNR

MPN: 5930-01-178-8451

Manufacturer: Pollak

Subminiature pushbutton, snap action Switch, solder Terminal, N.O. black bezel, red button. Meets the requirements of MIL-PRF-8805 with up to 5 amps at 28VDC.

MPN: 5930-01-185-6047

Manufacturer: Otto

Sealed Switch, 10 amps, 28 vdc, SPDT, Sealed per MIL-S-8805 symbol 4.

MPN: 5930-01-186-2732

Manufacturer: Honeywell

Toggle Switch

MPN: 5930-01-187-8027

Manufacturer: Otto
