Products Catalog
Electrical

Micro Switch AT Series Toggle Switch, SPDT - 1 pole, 2 position, Solder Terminal, Standard Lever, Fine silver contacts, long life construction, flat top plunger

MPN: 5930-00-840-2011

Manufacturer: Honeywell

Micro Switch Actuator. JX-51 is an auxiliary Actuator for select basic Switches. Corrosion resistant steel roller-see attached pdf for suitability. (Photo is only a sample of the product family).

MPN: 5930-00-842-0609

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, SPST - 1 pole, 2 position (OFF-ON), Screw Terminal, Locking Lever (D) - Locked out of center position, Military Part Number MS24658-22D. Ampere/Voltage Range (Resistive Load): 0.5 A to 20 A at 0.5 Vdc to 28 Vdc; 0.5 A to 15 A at 0.5 Vac to 277 Vac; 0.5 A at 250 Vdc; 0.75 A at 115 Vdc. UL/CSA L191: 15 A-125, 250, 277 Vac; 1/2 Hp-125 Vac; 1 Hp-250, 277 Vac; 5 A-120 Vac "L".

MPN: 5930-00-843-8990

Manufacturer: Honeywell

Micro Switch TL Series Sealed Toggle Switch, Single Pole Single Throw (SPST) 2 Position (Momentary ON - OFF), Screw Terminals, Standard Lever, Military Part Number MS24523-30. Ampere/Voltage Range (Resistive Load): 0.5 A at 250 Vdc; 0.75 A at 115 Vdc; 0.5 A to 15 A at 0.5 Vdc to 28 Vdc; 0.5 A to 10 A at 0.5 Vac to 277 Vac. UL/CSA L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "L".

MPN: 5930-00-847-7396

Manufacturer: Honeywell

Sealed Military Spec Pushbutton Switch. 10A, normally open SPST, Screw Terminals, Momentary, Black Button. Same a part # P1-32122. Hardware included.

MPN: 5930-00-847-9863

Manufacturer: Otto

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 2 position (ON-ON), Screw Terminal, Locking Lever (G) - Locked in extreme position (keyway), Military Part Number MS24659-23G.

MPN: 5930-00-856-1654

Manufacturer: Honeywell

Micro Switch HS Series premium large basic Switches fulfill the need. The HS Series design incorporates a MIL-PRF-8805 symbol 5 hermetic seal to comply with hermetic seal requirements. HS Series Switches are capable of controlling logic level/low energy applications, as well as power-duty Switching to solve many applications. With a compact package size, HS Series Switches have overall dimensions of 1.96 inch length, 1.18 inch height, and 0.67 inch wide and are suitable for applications where space is limited. In addition to MIL-PRF-8805 qualified HS Series Switches, UL and CSA certified HS Series basic Switches are available for a wide variety of applications.

MPN: 5930-00-857-5056

Manufacturer: Honeywell

Micro Switch ET Series Toggle Switch, 2 pole, Electrically held- 2 position, Solder T type Terminal, Standard Lever.

MPN: 5930-00-864-6515

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPDT - 2 pole, 3 position (Momentary ON - ON - ON), Screw Terminal, Locking Lever (M) - Locked out of and into extreme position (opposite keyway), Military Part Number MS27408-5M.

MPN: 5930-00-865-6784

Manufacturer: Honeywell

Micro Switch TL Series Toggle Switch, DPST - 2 pole, 2 position (OFF-ON), Screw Terminal, Locking Lever (D) - Locked out of center position, Military Part Number MS24659-22D.

MPN: 5930-00-878-6734

Manufacturer: Honeywell

XE Series Environmentally Sealed Basic Switch, Single Pole Double Throw Circuitry, 7 A at 115 Vac, Pin Plunger Actuator, Leadwire Termination, Military Part Number MS27994-1.

MPN: 5930-00-880-2312

Manufacturer: Honeywell

XE Series Environmentally Sealed Basic Switch, Single Pole Double Throw Circuitry, 7 A at 115 Vac, Pin Plunger Actuator, Leadwire Termination, Military Part Number MS27994-1.

MPN: 5930-00-880-2312

Manufacturer: Honeywell

XE Series Environmentally Sealed Basic Switch, Single Pole Double Throw Circuitry, 7 A at 115 Vac, Pin Plunger Actuator, Leadwire Termination, Military Part Number MS27994-1.

MPN: 5930-00-880-2312

Manufacturer: Honeywell

HM Series Hermetically Sealed Basic Switch, Single Pole Double Throw Circuitry, 5 A at 28 Vdc, Integral Lever Actuator, Solder Termination.

MPN: 5930-00-880-6485

Manufacturer: Honeywell

Environmentally Sealed Positive Action, MIL-DTL-8834 or MS25308-232,25A 28 VDC or 115 VAC 400 Hertz or 20A 115 VAC 60 Hertz Resistive Load, 4.P.D.T. ON-NONE-ON, Screw Terminals.

MPN: 5930-00-892-9393

Manufacturer: Safran

Miniature toggle Switch, SPST, On (MOM)-Off-On (MOM),.410 Bat,.350 Threaded Bushing, Solder Lug.

MPN: 5930-00-894-9483

Manufacturer: ElectroSwitch

Environmentally Sealed Positive Action Toggle Switch, two pole, Momentary ON- OFF - Momentary ON circuitry, Screw Terminals, 25A (resistive) at 28 VDC, 115 VAC and 400Hz; or 20A (resistive) at 115 VAC and 60Hz.

MPN: 5930-00-901-4275

Manufacturer: Safran

Environmentally Sealed Positive Action Toggle Switch, two pole, ON - NONE - Momentary ON circuitry, Screw Terminals, 25A (resistive) at 28 VDC, 115 VAC and 400Hz; or 20A (resistive) at 115 VAC and 60Hz.

MPN: 5930-00-901-4657

Manufacturer: Safran

Toggle, Miniature Positive Action, 5A @ 28 VDC, 3A @ 115 VAC @ 400 Hertz, 2A @ 115 VAC Resistive Load, D.P.D.T. Momentary ON-OFF-Momentary ON, Bushing Seal, Solder-Lug Terminals.

MPN: 5930-00-902-6868

Manufacturer: Safran

Miniature Positive Action Rugged Toggle Switch, 5A @ 28VDC, 3A @ 115 VAC 400 Hertz, 2A @ 115 VAC 60 Hertz Resistive Load, S.P.D.T. ON-OFF-ON, Bushing Seal. Mil qualified to MS90310-211, The Eaton 8868k1 has Solder-Lug Terminals.

MPN: 5930-00-902-6869

Manufacturer: Safran
