Products Catalog
Electrical

Hydraulic magnetic Circuit Breaker, 2 pole with screw Terminals, DC short delay, screw Terminals, rated at 10 amp, sealed toggle w/ bushing mounting. Other breakers in this same series are available-ask us!

MPN: 5925-01-606-3765

Manufacturer: Airpax

Fully sealed magnetic Circuit Breaker with auxiliary contacts, low power, trip free, two pole, screw Terminals, rated 3.0 amps, high inrush, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-606-3855

Manufacturer: Airpax

Hydraulic magnetic Circuit Breaker, three pole with bushing plus (2) 6-32 threaded inserts, screw Terminals, 50/60Hz long time delay , 15 amps. The AP, UP fully sealed, magnetic Circuit Breaker combines power Switching and accurate, reliable circuit protection. See specifications for product details.

MPN: 5925-01-608-8958

Manufacturer: Airpax

Hydraulic magnetic Circuit Breaker, two pole with bushing plus (2) 6-32 threaded inserts, hook Terminals, DC short time delay, 8 amps The AP, UP fully sealed, magnetic Circuit Breaker combines power Switching and accurate, reliable circuit protection with inverse time delays and trip free features.For more info on creating MIL specific part numbers, please visit : MIL-PRF-39019 on hyperlink below.

MPN: 5925-01-609-8561

Manufacturer: Airpax

Thermal 50 amp Circuit Breaker. Ignition protected and sealed.. Auto reset. Over-current protection for harsh environments, vehicle, electric vehicle, battery chargers, marine, etc..

MPN: 5925-01-610-3305

Manufacturer: Sensata

Fully sealed magnetic Circuit Breaker, low power, trip free, one pole, screw Terminals, rated 2.0 amps, standard delay, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-612-1007

Manufacturer: Airpax

Military Spec thermal magnetic Circuit Breaker. Circuit protection unaffected by temperature fluctuations. High vibration resistance and high interrupting capacity. 100 amp.

MPN: 5925-01-614-3488

Manufacturer: Sensata

Thermal Circuit Breaker- Single Pole 15 amp push/pull Actuator for manual reset and actuation, UL, CSA, 8-32 Screws.

MPN: 5925-01-615-6918

Manufacturer: TE

Commercial thermal Circuit Breaker. 30 amps. Sealed & ignition protected. Automatic reset.; For battery protection in electric vehicles & marine. Ignition protected to SAE J1171: Weatherproof to SAE J553. UL Recognized to E3686. 7854-15-30-I features a self locking insert for easy mounting. Stud Terminals .61 inch stud Terminal length.

MPN: 5925-01-616-3924

Manufacturer: Sensata

Hydraulic magnetic Circuit Breaker, two pole with bushing plus (2) 6-32 threaded inserts, hook Terminals, 50/60Hz long time delay, 7.500 amps The AP, UP fully sealed, magnetic Circuit Breaker combines power Switching and accurate, reliable circuit protection with inverse time delays and trip free features.For more info on creating MIL specific part numbers, please visit : MIL-PRF-39019 on hyperlink below.

MPN: 5925-01-619-6264

Manufacturer: Airpax

Circuit Breaker Hydraulic Magnetic 2 Pole unit plus (2) 6-32 threaded inserts.; 7A, 50/60Hz long time delay. 240VAC

MPN: 5925-01-623-8015

Manufacturer: Airpax

Fully sealed magnetic Circuit Breaker with auxiliary contacts, low power, trip free, one pole, screw Terminals, rated 15 amps, high inrush, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-626-4378

Manufacturer: Airpax

Hydraulic magnetic Circuit Breaker, 2 pole with screw Terminals, DC/60Hz short delay, rated at 2.5 amps, sealed toggle w/ bushing mounting. Other breakers in this same series are available-ask us!

MPN: 5925-01-629-1410

Manufacturer: Airpax

Thermal 105 amp Circuit Breaker. Ignition protected and sealed.. Auto reset. Over-current protection for harsh environments,vehicle,electric vehicle,battery chargers,marine,etc.

MPN: 5925-01-630-3607

Manufacturer: Sensata

Hydraulic magnetic Circuit Breaker, double pole, screw Terminals, 50/60Hz short delay, rated 10 amps @ 80VDC/240VAC, black toggle Handle marked ON-OFF. VDE and CCC approved, UL-1077 Recognized. Other breakers in this same series are available-ask us!

MPN: 5925-01-632-1897

Manufacturer: Airpax

Hydraulic magnetic Circuit Breaker

MPN: 5925-01-640-8256

Manufacturer: Airpax

Military Spec thermal magnetic Circuit Breaker. Circuit protection unaffected by temperature fluctuations. High vibration resistance and high interrupting capacity. 75 amp.

MPN: 5925-01-641-2817

Manufacturer: Sensata

Fully sealed magnetic Circuit Breaker, low power, trip free, one pole, screw Terminals, rated 1.5 amps, standard delay, 50V DC and 240V AC @ 60 Hz and 400Hz. QPL to MIL-PRF-39019.

MPN: 5925-01-642-1526

Manufacturer: Airpax

Thermal 20 amp Circuit Breaker. Precision,sealed and ignition protected. Auto reset. Self locking mounting nut for easy installation. Excellent over-current protection for harsh environments.

MPN: 5925-01-650-5714

Manufacturer: Sensata

Circuit Breaker, Type 3 phase, push-pull, trip free, 20 amps. FAA approved part number 10-60806-1020

MPN: 5925-01-652-6456

Manufacturer: Sensata
