Micro Switch SX Series Subminiature Basic Switch, Single Pole Double Throw (SPDT), 250 Vac, 7 A, Pin Plunger Actuator, Solder Termination, Military Part Number MS24547-4.

MPN: 5930-01-108-8542

Manufacturer: Honeywell

Auxiliary Actuator for Environment-sealed basic Switch, roller lever

MPN: 5930-01-110-3876

Manufacturer: Honeywell

2 circuit Alternate Action Moisture Proof Pushbutton Switch, snap action contacts. See pdf. Red button. Note-we will show no stock because we build them here from sub-components-allow 10 days for delivery but they are NCNR. Photo shows gray but actual button is red! Assembly items that are in stock need at least 24 hours to process prior to shipping.

MPN: 5930-01-112-8402

Manufacturer: Safran

Rectangular, Standard Bezel, Lighted, 1 Incandescent Lamp, DPST NO Form X , Alternate Action, Snap in Panel mount.

MPN: 5930-01-113-6839

Manufacturer: Honeywell

AML series pushbutton Switch. AML21FBA2BC, electronic control pushbutton, rectangle, black bezel, lighted. 1 Incandesent Lamp, DPDT, momentary action, gold contacts, snap in Panel mount.

MPN: 5930-01-114-9876

Manufacturer: Honeywell

Special purpose PushButton Start Switch, SPST, 35A at 12V, 20A at 24V DC. Two screw Terminals with lockwashers. Mounting stem 7.8""-24 thread, keyed to prevent Switch from turning, fits Panels 0.04" - 0.10" thick (1.0 - 2.5mm). Silver contacts. Button is engraved "Engine Start". Impact-resistant molded plastic button with imprint, white on color, repels oil, water and other liquids. Diecast housing, with knurled aluminum facenut. 2.2"L overall, 1.1" case diameter (56.1 and 28.5mm). With special facenut with built-in lip seal for added weather-resistance. Same as 90047-01 BX.

MPN: 5930-01-115-5122

Manufacturer: LittelFuse

Special 4 way toggle Switch with an operating force of 24-30 ounces. This OTTO mini trim Switch has SPST ( 4 Switches), quiet operation, sealed, momentary action. Please refer to pdf.

MPN: 5930-01-115-9238

Manufacturer: Otto

Miniature positive action toggle Switch with solder lug Terminal to MIL-S-8834. MS90311-731 is a double pole Switch with on none on circuitry.

MPN: 5930-01-116-5532

Manufacturer: Safran

Switch. The T2-0011 features two functions in one Switch; Pushbutton & Toggle. Type 4 Resilient Seal per MIL-S-8805. Features toggle lockout when pushbutton mode is actuated Pushbutton lockout when in toggle mode. Splash proof and dust tight seal.

MPN: 5930-01-118-0131

Manufacturer: Otto

Pushbutton Switch. Double pole double throw double break. Splash and Dusttight Sealed, 2 Pole, 4 Circuit. Operating Force: 4.0 lbs. +/- 1.0 lb. Circuit: DPDT 4 circuit. Rating: 5 amps Resistive 3 amps, Inductive Contacts: Gold plate per MIL-PRF-8805/101-010, Button: Black nylon.

MPN: 5930-01-123-9994

Manufacturer: Otto

30 amp overload Sensor. Klixon 7235 and 7236 overload sensing controls are designed for the remote sensing of overloads in aircraft electrical systems or other appliCable remote systems. They are for the protection of 28 VDC circuits or for 120 VAC single phase or three phase circuits operating at 60 to 1000 Hz. For three phase AC circuit protection, a 28 VDC control circuit is required. One three phase Relay or three single phase Relays with their coils wired in series may be used in the control circuit. With either arrangement, all three phases will trip open simultaneously when an overload exists in any one phase. See attached spec sheet.

MPN: 5930-01-124-6879

Manufacturer: Sensata

ET series toggle Switch.29ET3 is 4 pole, electrically held 3 position Switch. Leadwire termination with standard lever.

MPN: 5930-01-126-2875

Manufacturer: Honeywell

Military spec locking toggle Switch. 2 pole bonded seal (ON - NONE - ON). 8856K8X has Positive make and break action and Solder lug termination.

MPN: 5930-01-126-8262

Manufacturer: Safran

Micro Switch TS Series Toggle Switch, SPST - 1 pole, 2 position (OFF-ON), Screw Terminal, Standard Lever.

MPN: 5930-01-133-3657

Manufacturer: Honeywell

Environmentally sealed limit Switch.;Plunger actuated, DPDT, NO/NC, 4 Amps / 28 Volts DC.

MPN: 5930-01-135-1677

Manufacturer: Honeywell

Micro Switch Straight lever Auxiliary Actuator for SX series Switches

MPN: 5930-01-140-2645

Manufacturer: Honeywell

Temperature range between -55 C to + 85 C. 28 VDC or 115 VAC, 10 Amp. Dust tight. Per MIL-S-8805, design 2. Nylon grey button. Black and anodized aluminum alloy case. 2 circuits. Please see drawing for more information.

MPN: 5930-01-143-9156

Manufacturer: Otto

Mil spec sub-miniature pushbutton Switch, 7A & 28 VDC & 125 VAC,S.P.S.T.-N.O. Momentary, Dust Sealed, Black Button & Case, Solder-Lug Terminals. BW9001BB is mil spec to M8805/96-014 and same as Eaton BW9001B except it has a black case. Special price for Inventory on hand only!

MPN: 5930-01-149-8527

Manufacturer: Safran

Switch roller lever Assembly, Actuator Switch.

MPN: 5930-01-156-1382

Manufacturer: Honeywell

Controls mil grade pushbutton snap action Switch for low level Switching. Sealed with momentary action, normally open. 4 LBS momentary Switch action. Screw Terminals. Black body & button. Hardware is included. Mil qualified to MS25089-1CL. Same as Otto P1-34122.

MPN: 5930-01-163-3415
