M39029/57-358 Electrical Contact Pin

Name: Electrical Contact Pin
Brand: PRECI-DIP
SKU: 5999001973621
Price: 1.75 USD
Availability: InStock

Part#: M39029/57-358 NSN: 5999-00-197-3621

About this product M39029/57-358 Electrical Contact Pin. * Manufacturer certifications are shipped with your order FREE of charge

Product Images

Product Details

Part Number or Model	M39029/57-358
Description	Electrical Contact Pin
Schedule B Class
ECCN (Export Control Class)	EAR99
Specification Data	81349-mil-c-39029/57 government specification
Special Features	Basic item identification number bin-358
Precious Material And Weight	0.010 gold grains, troy
Precious Material And Location	Body and contact surfaces gold
Precious Material	Gold
Pin Accommodation Length	0.209 inches minimum and 0.229 inches maximum
Pin Accommodation Diameter	0.066 inches minimum and 0.068 inches maximum
Overall Length	0.518 inches nominal
Overall Diameter	0.127 inches minimum and 0.130 inches maximum
Mounting Method	Force fit
Material	Copper alloy body
Material	Copper alloy contact
Crimping Tool Identifying Number	M22520/7-01
Identification Code Color	Orange and green and gray
Cable Entrance Diameter	0.113 inches nominal
Style Designator	Socket contact
Surface Treatment	Gold body and copper body
Surface Treatment	Gold contact and copper contact
Surface Treatment Specification	Mil-g-45204 mil spec single treatment response body and contact
Terminal Type And Quantity	1 crimp axially at one end

Up to quantity 475 ships same day.

buy now $1.75

each, minimum order quantity of 25 Sold in increments of 25

Request a quote Call for questions and assistance
+1 (321) 802-5889

AeroBase Group is an ISO 9001:2015 + AS9120B audited and certified supplier.
